OLP-400OLP-400
| TECHNICAL INFORMATION | OLP 400 | ||
| WORKING WEIGHT | SIDE CONNECTION | kg | 430 |
| lb | 946 | ||
| TOP CONNECTION | kg | 420 | |
| lb | 924 | ||
| BOX TYPE | kg | 460 | |
| lb | 1.012 | ||
| CARRIER WEIGHT | Skid Steer Loader | Ton | 4.8~7.5 |
| 1000*Lb | 10.56~16.5 | ||
| MINI EXCAVATOR BCKHOE LOADER | Ton | 6~10 | |
| 1000*Lb | 13.2~22 | ||
| IMPACT ENERGY | joule | 980 | |
| ft.lb | 723 | ||
| IMPACT FREQUENCY | BPM | 450~1.000 | |
| MIN. & MAX. OIL SUPPLY | LPM | 45~100 | |
| GPM | 11.9~26.4 | ||
| OPERATING PRESSURE | bar | 120 | |
| psi | 1.740 | ||
| RELIEF PRESSURE | bar | 170~180 | |
| psi | 2.465~2.610 | ||
| BACK PRESSURE (max) | bar | 20 | |
| psi | 290 | ||
| TOOL DIAMETER | mmØ | 80 | |
| inØ | 3,15 | ||
