OLP-300OLP-300
| TECHNICAL INFORMATION | OLP 300 | ||
| WORKING WEIGHT | SIDE CONNECTION | kg | 300 |
| lb | 660 | ||
| TOP CONNECTION | kg | 310 | |
| lb | 682 | ||
| BOX TYPE | kg | 340 | |
| lb | 748 | ||
| CARRIER WEIGHT | Skid Steer Loader | Ton | 2.5~4.2 |
| 1000*Lb | 5.5~9.24 | ||
| MINI EXCAVATOR BCKHOE LOADER | Ton | 4.5~7 | |
| 1000*Lb | 9.9~15.4 | ||
| IMPACT ENERGY | joule | 840 | |
| ft.lb | 620 | ||
| IMPACT FREQUENCY | BPM | 390~1.000 | |
| MIN. & MAX. OIL SUPPLY | LPM | 30~65 | |
| GPM | 7.9~17.1 | ||
| OPERATING PRESSURE | bar | 120 | |
| psi | 1.740 | ||
| RELIEF PRESSURE | bar | 170~180 | |
| psi | 2.465~2.610 | ||
| BACK PRESSURE (max) | bar | 20 | |
| psi | 290 | ||
| TOOL DIAMETER | mmØ | 70 | |
| inØ | 2,76 | ||
